12OPERATING INSTRUCTIONS MN280067EN July 2017
Type MET electronic recloser control tester operating instructions
Accessory cat. no. Description Drain (mA) Remarks
KA1037ME Instantaneous trip-all multipliers 0 If phase disabled.
0 If accessory active.
0 If ground disabled.
KA1137ME Targets, auto/manual reset – See KA1025ME.
KA1119ME Capacitor trip backup 0
KA1122ME Capacitor trip backup 0
KA1163ME Minimum response time 0 For any programmed sequence.
KA2003ME Remote close with cold-load and non-reclose 0
KA2035ME2 Remote non-reclose and remote ground trip block, maintained .22 Supervisory contacts open.
.85 Supervisory contacts closed.
KA2039ME2 Recloser status .06 Recloser Open
.16 Recloser Closed
KA2047ME Remote battery test and voltage monitor .1
KA2070ME2 Remote close with cold load pickup and recloser status .06 Recloser Open
.16 Recloser Closed
0 Supervisory contacts open.
29 Supervisory contacts closed.
KA2071ME Remote non-reclose and remote ground trip block, maintained 0 Supervisory contacts open.
36 Supervisory contacts closed.
KA2072ME Remote battery test and voltage monitor, with analog output. 1
KA2189ME Remote fault target indicator 0
KA2230ME Supervisory selector switch 0
