Page #76 background imageLoading...
Page #76 background image
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
416 Features Leader/
Follower
416 Leader/Follower
Timeout
XX Seconds
0 2 NA 10 1 60
The length of time in seconds before the Leader returns to starting tap position if a Follower device does not tap.
417 Features Leader/
Follower
417 Leader/Follower
Retry Delay
XX Seconds
0 2 NA 5 5 60
The length of time in seconds before the leader retries to initiate a tapping operation if an initial attempt failed.
418 Features Leader/
Follower
418 Leader/Follower
Retries
XX
0 2 NA 3 1 10
The number of tap retries before the Leader stops retrying taps. Enter the number of times to retry tapping.
420 Features Leader/
Follower
420 Leader/Follower
Monitor
Disabled
NA NA NA NA NA NA
This is the state of the leader Follower Monitor. It will display either enabled or disabled.
450 Features Alternate
Config
450 Alternate
Configuration
Off
0 2 NA OFF NA NA
This will turn on Alternate Configurations. The options are:
• Off • On • ARLH • ARLC • P.I.O.
Selecting "On" will enable the basic Alternate Configuration settings.
Selecting ARLH will enable the Auto-Restore Local Heartbeat function. This function will revert control settings modified
through SCADA communications back to original settings when a heartbeat signal is lost or discontinued.
Selecting ARLC will enable the Auto-Restore Local Comms function. This function will revert control settings modified
through SCADA communications back to original settings when a communications signal is lost.
Selecting P.I.O. will enable Alternate Configuration settings to be enabled or disabled using P.I.O. logic equations.
451 Features Alternate
Config
451 Alternate
Configuration
Inactive
0 NA NA NA NA NA
This is the state of Alternate Configuration. It will display either Active or Inactive.
TABLE 5-3. Function Codes (continued)
70
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
