4 EATON 620 Mobile Open Circuit Piston Pump Service Manual E-PUPI-TS018-E2 November 2017
Part identification
Standard seal kit: 9900758-000
Adjustable maximum displacement volume stop kit: 9900772-000
Item Part number Quantity Description Page number
1 See table 1 1 Housing 11
2 See table 2 1
Seal, shaft
12
3 101680-225 1
Ring, retaining, internal (Seal, shaft)
06
4 6021805-001 1 Bearing assembly, shaft (front) 06
5 5989757-001 1 Spring, bias 06
6 6021043-001 2 Bearing, swashplate / bearing kit 9900761-000 06
7 114995-010 2 Screw, cap, socket / bearing kit 9900761-000 06
8 See table 3 1 Swashplate 12
9 See table 4 1 Shaft, drive and key 13
10 See table 4 1 Key, driveshaft 13
11 See table 5 1 Rotating group S/A 14
12 See table 6 1 Plate valve 14
13 See table 7 1 Bearing assembly, shaft (rear) 15
14 Not Saleable 1 Ring, crush / bearing shim kit 9900776-000 06
15 96201-062 2 Slotted spring pin 1/4 06
16 6026023-001 1
Gasket (endcover/ housing)
06
17 See table 7 1 End cover S/A 15
18 114978-050 4 Screw, cap (housing/ endcover) 06
19 See table 9 1 Piston, control 16
20 See table 10 1
Plug, adjustable volume stop
16
21 See table 11 1 Plug (top case drain port) 17
22 See table 11 1 Plug (bottom case drain port) 06
23 115046-004 1 Plug (housing) 06
24 107275-017 1
O-ring (compensator/housing)
06
25 107275-011 2
O-ring (secondary compensator/housing)
19
26 See table 12 1 Compensator kits 17
27 See table 13 4 Screw, cap (compensator mounting) 18
28 See table 14 1 Coupler 18
29 104166-155 1
O-ring (end cover to aux mount)
/ thru drive adapter kit)
19
30 See table 15 1 Adapter, thru drive / thru drive adapter kit 19
31 See table 14 1
O-ring adapter
/ thru drive adapter kit
19
32 See table 14 4 Bolts / Thru drive adapter kit 19
33 See table 16 1 Cold start manifold (Destroke) 19
34 107275-011 3 O-ring (Destroke) 19
35 6022841-001 1 Link, feedback 38
