Eaton 620 - Page 9

9EATON 620 Mobile Open Circuit Piston Pump Service Manual E-PUPI-TS018-E2 November 2017
48
29
28
17
18
30
32
49
31
4 X Torque
30 ± 5.4 Nm
Torque
115± 12 Nm
Optional assembly
47
20
45
4 X Torque
161 ± 16.0 Nm
4 X Torque
27 ± 2.7 Nm
46
Adjustable maximum stop option
Thru-drive part option
