Eaton EASY-E4-UC-12RCX1 Instruction Leaflet

08/21 IL050020ZU
5/8
Ethernet
EASY-E4-...-..C(X)1 EASY-E4-...-..P
0.5 - 0.7 Nm
3.5 mm
1
2
1
2
1
2
6.5 mm (0.26“)
0.2 - 2.5 mm
2
0.2 - 4 mm
2
0.2 - 2.5 mm
2
AWG 22 - 12
8 mm (0.31“)
0.25 - 1.5 mm
2
8 mm (0.31“)
0.2 - 2.5 mm
2
AWG 24 - 14
8 7 6 5 4 3 2 1
RJ45
EASY-E4-DC-12TC1
(P)
EASY-E4-DC-12TCX1(P)
EASY-E4-AC-12RC1(P)
EASY-E4-AC-12RCX1(P)
EASY-E4-UC-12RC1(P)
EASY-E4-UC-12RCX1(P)
PIN Ethernet 10/100 MBit
8
–
7
–
6
Rx –
5
–
4
–
3
Rx +
2
Tx –
1
Tx +
