Installation and User manual for the
conventional range of fire panels
EATON www.eaton.com
Technical Data PR000-00-513-05
Effective January 2018
Technical Specifications
Panel Specification 2-Zone 4-Zone
Zone Circuits
Number of Zones 2 4
Devices per Zone 30 Detectors/Manual Call Points
EOLM-1 Only
End of Line Termination
Sounder Circuits
Number of Sounder Circuits 2 2
Maximum Loading 300mA total (share) 800mA total (share)
Fuse Protection 400mA Polyswitch
(PTC2, PTC3)
1.1A Polyswitch
(PTC2, PTC3)
End of Line Termination 6K8 resistor
Unmonitored Outputs
Fire/Fault Relay Type Volt-Free, Change Over Contacts
Rating 5 Amps @ 30V dc
Fuse 5 Amp Glass Fuse (F2)
Located Main board
Mode Configurable as Fire or Fault Relay
Fire Relay Type N/A
Rating N/A
Fuse N/A
Located N/A
Mode N/A
Auxiliary Output V 24V dc
Imax 30 mA
Fuse Polyswitch (PTC5)
Located Main board
Unmonitored Inputs
Class Change Open Circuit = Normal Panel Operation
Short Circuit = Activate All Sounders
Communication Ports
Repeater Port Type RS485
Nodes Cascading
Environmental
Operating Temperature
°C -5°C to +40°C
Relative Humidity % 75% non-condensing
IP Rating IP30
Mechanical
Dimensions mm 332 (W) x 270 (H) x 90 (D)
Weight kg
5.2 5.8
Material PC ABS Front and Rear
Cabling
Cable Access 12 x 20mm positions
4 x slots for rear cable entry
Cable Type Firetuf FT120 / FP200
Cable type 2 core 1.5mm, screened fire rated cable
Compliance
Compliance to Standards EN54 Part 2 CIE and Part 4 PSE, BS5839, part1
