5 Function blocks
5.16 HY - Year Time Switch
Manual 11/10 MN05002001Z-EN www.eaton.com 285
5.16.4.4 Cycle time
5.16.5 How the function block works
The year time switch can switch ranges, individual days, months, years or
combinations of all three.
Years
Switching at 00:00:
• On on 01.01.2008 and
• Off on 01.01.2013.
Months
Switching at 00:00:
• On on 01 April every year.
• Off on 01 November every year.
Days
Switching at 00:00:
• On on the 2nd day of every month.
• On on the 26th day of every month.
5.16.6 Entry rules
The contact switches (ON to OFF)
• in the years.
• in the defined months.
• on the entered days.
mode Cycle time [μs]
- 61
HY01 A +
>ON --.--.08
>OFF --.--.12
HY01 A +
>ON --.04.--
>OFF --.10.--
HY01 A +
>ON 02.--.--
>OFF 25.--.--
CAUTION
The year time switch only operates correctly if you observe the
following rules:
• The On year must be before the Off year,
• ON and OFF times must be specified the same in pairs, for
example:
• ON = Day/--/--, OFF = Day/--/--
• ON = --/--/Year, OFF = --/--/Year,
• ON = --/Month/Year, OFF = --/Month/Year
• ON = Day/Month/Year, OFF = Day/Month/Year
• Normally, the ON day should be before the OFF day;
otherwise, the exception described on Example 8
(
￫ section “ Example 8: Selecting a time range of two days
spanning the turn of the year (2-channel)”, page 289) on
applies.
