Eaton NZM1 Series User Manual

2/2 Emergency On Call Service: Local representative (www.eaton.eu/aftersales) or +49 (0) 180 5 223822 (de, en)
04/16 IL01219013Z
Eaton Industries GmbH, Hein-Moeller-Straße 7-11, 53115 Bonn, Germany
© 2002 by Eaton Industries GmbH, www.eaton.eu/documentation
All Rights Reserved
04/16 IL01219013Z 12271565/DE17 Doku
Printed in Germany (04/16)
NZM1(-4)-XKS
NZM1(-4)-XKSA
(Connector pads for Compression Crimp Lugs)
Use ferrules with flexible and highly flexible conductors.
Bei feindrähtigen und hochflexiblen Leitern Aderendhülsen
verwenden.
Pour les conducteurs souples et extra-souples, utiliser
des embouts.
Para conductores flexibles y muy flexibles deben utilizarse
terminales.
Per conduttori flessibili e altamente flessibili utilizzare
capicorda.
对于多股和非常容易弯曲的线缆可以使用线缆衬套
Для тонкопроволочных и очень гибких жил требуется
использовать наконечники.
NZM1(-4)-XKA
NZM1(-4)-XKSA
(Barrel Type Mechanical Lugs)
NZM1(-4)-XKSA
(Terminal cover and isolating base)
4 mm
f 40 mm
(f 1.57”)
4a
3
4 mm
9 Nm (79.65 lb-in)
M6 x 18

In all cases, it is necessary to install
the terminal cover and isolating base
plate Type NZM1-XKSA (provided) in
order to maintain proper clearances.
4 mm
9 Nm (79.65 lb-in)
M6 x 14
1
2
16.5 mm
(0.65”)
F 8 mm (F 0.31”)
F16 mm
(
F 0.63”
)
F 6 mm
(
F 0.2 4”
)
o 6.5 mm
(o 0.26 ”)
f
400 mm
(
f
15.75“)
1 x (12 - 16 ) x 5
1 x (0.47“ - 0.62“ ) x 0.19 “
b
a
o
c
mm in
a ≦ 10 ≦ 0.39
b ≦ 16 ≦ 0.63
c ≦ 7 (2 x 3.5) ≦ 0.27 (2 x 0.1 4)
⌀ 6.5 0.25
n = Number of crimps
n = Anzahl der Pressungen
n = Nombre de sertissages
n = Número de compresiones
n = Numero delle crimpature
n = Число прессований
n = 2
Cu 1 x 10 - 70 mm
2
2 x 6 - 25 mm
2
Al 1 x 10 - 35 mm
2
2 x 10 - 35 mm
2
1 x AWG 12 - 1 x AWG 2/0
Cu only, Ampacity per 75 °C Table
4b
3
4
5 mm
15 Nm
(133 lb-in)
2
1
4 mm
9 Nm (79.65 lb-in)
Control circuit terminal
Steuerleitungsanschluss
Borne pour conducteur de commande
Tornillo para cable de mando
Collegamento cavo di comando
Присоединение к линии управления
Cu only
1 x 0.75 - 2.5 mm
2
1.2 Nm
2 x 0.75 - 1.5 mm
2
(11 lb-in)
1 x AWG 18 - 14
Cu 1 x 16 - 95 mm
2
Al 1 x 16 - 95 mm
2
1 x AWG 3/0 - 6
1
3
2
Z 2
1 Nm (9 lb-in)
60 mm (2.36“)
In all cases, it is necessary to install
the terminal cover and isolating base
plate Type NZM1-XKSA (provided) in
order to maintain proper clearances.


Eaton NZM1 Series Specifications

General

Series	NZM1
Number of Poles	1, 2, 3, 4
Operating Temperature	-25°C to +70°C
Protection Degree	IP20
Type	Circuit Breaker
Rated Voltage	690 V
Standards	IEC/EN 60947-2
Trip Unit	Thermal-magnetic, Electronic
Mounting	Fixed, Plug-in
