11 Modbus register map

PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com

11.3.2 Real-time data object registers

The data changing in real time, such as current, voltage, power, etc. are shown in the table

below. Real time data can be obtained either in IEEE floating point or in fixed point format.

For data shown in fixed point format, each result would be the real time data multiplied by

a scale factor. The scale factors are shown as the last column in the table. Energy objects

can be only obtained in fixed point format.

Each data object occupies two registers (four bytes) in length except for certain energy

objects. These energy objects occupy four registers. Since these objects have the capability

to change in real time, a complete data object must be obtained in a single transaction to

avoid data tearing. Attempting to access a partial data object will result in an exception code

84. Refer to a later section entitled “Exception codes”.

address (HEX) Objects Trip Unit

IEEE

float

Fixed

point (FP)

IEEE

float

Fixed

point (FP) Descriptions Units

Fp scale

factor

PXR

20/20D

PXR

25MP

404609 406145 1200 1800 High byte is primary status, low byte is

secondary status (see Section 11.3.8.2)

YES YES YES

404610 406146 1201 1801 Cause of status (see Section 11.3.8.2) YES YES YES

404611 406147 1202 1802 IA A 10 YES YES YES

404613 406149 1204 1804 IB A 10 YES YES YES

404615 406151 1206 1806 IC A 10 YES YES YES

404617 406153 1208 1808 IG A 10 YES YES YES

404619 406155 120A 180A IN A 10 YES YES YES

404623 406159 120E 180E VAB V 10 YES YES

404625 406161 1210 1810 VBC V 10 YES YES

404627 406163 1212 1812 VCA V 10 YES YES

404631 406167 1216 1816 VAN V 10 YES YES

404633 406169 1218 1818 VBN V 10 YES YES

404635 406171 121A 181A VCN V 10 YES YES

404641 406177 1220 1820 Peak Ia demand A 10 YES

404643 406179 1222 1822 Peak Ib demand A 10 YES

404645 406181 1224 1824 Peak Ic demand A 10 YES

404649 406185 1228 1828 Peak In demand A 11 YES

404651 406187 122A 182A Real 3 phase power W 1 YES YES

404653 406189 122C 182C Reactive 3 phase power Vars 1 YES YES

404655 406191 122E 182E Apparent 3 phase power VA 1 YES YES

404659 406195 1232 1832 Power factor 100 YES YES

404661 406197 1234 1834 Frequency Hz 10 YES YES

404665 406201 1238 1838 minimum Ia demand A 10 YES

404667 406203 123A 183A minimum Ib demand A 10 YES

404669 406205 123C 183C minimum Ic demand A 10 YES

404673 406209 1240 1840 minimum In demand A 10 YES

404697 406233 1258 1858 Real power peak demand W 1 YES YES

404719 406255 126E 186E Product ID YES YES YES

404721 406257 1270 1870 Frequency Hz 100 YES YES

406259 1872 Forward energy KWh 1 YES YES

406261 1874 Reverse energy KWh 1 YES YES

406263 1876 Total energy KWh 1 YES YES

406271 187E Apparent energy KVAh 1 YES YES

404765 406301 129C 189C Temperature C 1 YES YES YES

406305 18A0 Forward energy Wh 1 YES YES

406309 18A4 Reverse energy Wh 1 YES YES

406313 18A8 Total energy Wh 1 YES YES

406329 18B8 Apparent energy VAh 1 YES YES
