11 Modbus register map

PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com

address (HEX) Objects Trip Unit

IEEE

float

Fixed

point (FP)

IEEE

float

Fixed

point (FP) Descriptions Units

Fp scale

factor

PXR

20/20D

PXR

25MP

404797 406333 12BC 18BC Reactive power peak demand Vars 1 YES YES

404799 406335 12BE 18BE Apparent power peak demand VA 1 YES YES

404835 406371 12E2 18E2 Ia demand A 10 YES

404837 406373 12E4 18E4 Ib demand A 10 YES

404839 406375 12E6 18E6 Ic demand A 10 YES

404843 406379 12EA 18EA In demand A 10 YES

404845 406381 12EC 18EC Real power demand W 1 YES YES

404847 406383 12EE 18EE Reactive power demand Vars 1 YES YES

404849 406385 12F0 18F0 Apparent power demand VA 1 YES YES

404851 406387 12F2 18F2 Minimum IA A 10 YES YES YES

404853 406389 12F4 18F4 Maximum IA A 10 YES YES YES

404855 406391 12F6 18F6 Minimum IB A 10 YES YES YES

404857 406393 12F8 18F8 Maximum IB A 10 YES YES YES

404859 406395 12FA 18FA Minimum IC A 10 YES YES YES

404861 406397 12FC 18FC Maximum IC A 10 YES YES YES

404863 406399 12FE 18FE Minimum IG A 10 YES YES YES

404865 406401 1300 1900 Maximum IG A 10 YES YES YES

404867 406403 1302 1902 Minimum IN A 10 YES YES YES

404869 406405 1304 1904 Maximum IN A 10 YES YES YES

404871 406407 1306 1906 Minimum VAB V 10 YES YES

404873 406409 1308 1908 Maximum VAB V 10 YES YES

404875 406411 130A 190A Minimum VBC V 10 YES YES

404877 406413 130C 190C Maximum VBC V 10 YES YES

404879 406415 130E 190E Minimum VCA V 10 YES YES

404881 406417 1310 1910 Maximum VCA V 10 YES YES

404883 406419 1312 1912 Minimum VAN V 10 YES YES

404885 406421 1314 1914 Maximum VAN V 10 YES YES

404887 406423 1316 1916 Minimum VBN V 10 YES YES

404889 406425 1318 1918 Maximum VBN V 10 YES YES

404891 406427 131A 191A Minimum VCN V 10 YES YES

404893 406429 131C 191C Maximum VCN V 10 YES YES

404911 406447 132E 192E current phase unbalance % 100 YES

404913 406449 1330 1930 voltage phase unbalance % 100 YES

404915 406451 1332 1932 Ia% THD % 100 YES

404917 406453 1334 1934 Ib% THD % 100 YES

404919 406455 1336 1936 Ic% THD % 100 YES

404923 406459 133A 193A In% THD % 100 YES

404925 406461 133C 193C Vab% THD % 100 YES

404927 406463 133E 193E Vbc% THD % 100 YES

404929 406465 1340 1940 Vca% THD % 100 YES

404931 406467 1342 1942 Van% THD % 100 YES

404933 406469 1344 1944 Vbn% THD % 100 YES

404935 406471 1346 1946 Vcn% THD % 100 YES

404959 406495 135E 195E INST/SDT/HIGH_INST count 1 YES YES YES

404961 406497 1360 1960 LDT/GFT count 1 YES YES YES

404963 406499 1362 1962 Operations count 1 YES YES YES

404965 406501 1364 1964 Short delay trip count 1 YES YES YES

404967 406503 1366 1966 Inst delay trip count 1 YES YES YES

404969 406505 1368 1968 High current delay trip count 1 YES YES YES
