11 Modbus register map

PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com

address (HEX) Objects Trip Unit

IEEE

float

Fixed

point (FP)

IEEE

float

Fixed

point (FP) Descriptions Units

Fp scale

factor

PXR

20/20D

PXR

25MP

404971 406507 136A 196A Long delay trip count 1 YES YES YES

404973 406509 136C 196C Ground fault trip count 1 YES YES YES

404975 406511 136E 196E Total trip count 1 YES YES YES

404977 406513 1370 1970 Test trip count 1 YES YES YES

404979 406515 1372 1972 Open by comm count 1 YES YES YES

404981 406517 1374 1974 Manual open count 1 YES YES YES

404983 406519 1376 1976 Time of last operation (year) 1 YES YES YES

404985 406521 1378 1978 Time of last operation (month) 1 YES YES YES

404987 406523 137A 197A Time of last operation (day) 1 YES YES YES

404989 406525 137C 197C Time of last operation (hour) 1 YES YES YES

404991 406527 137E 197E Time of last operation (minute) 1 YES YES YES

404993 406529 1380 1980 Time of last operation (second) 1 YES YES YES

404995 406531 1382 1982 Max device temperature 1 YES YES YES

404997 406533 1384 1984 Time of max device temp (year) 1 YES YES YES

404999 406535 1386 1986 Time of max device temp (month) 1 YES YES YES

405001 406537 1388 1988 Time of max device temp (day) 1 YES YES YES

405003 406539 138A 198A Time of max device temp (hour) 1 YES YES YES

405005 406541 138C 198C Time of max device temp (minute) 1 YES YES YES

405007 406543 138E 198E Time of max device temp (second) 1 YES YES YES

405009 406545 1390 1990 Running time: minute 1 YES YES YES

405011 406547 1392 1992 Running time: hour 1 YES YES YES

405013 406549 1394 1994 Running time: day 1 YES YES YES

405015 406551 1396 1996 Health points (0-10000) 100-(Health

point/100)

YES YES YES

405025 406561 13A0 19A0 harmonics are for:

0 - Ia

1 - Ib

2 - Ic

4 - In

5 - Vab

6 - Vbc

7 - Vca

8 - Van

9 - Vbn

10 - Vcn

1 YES

405027 406563 13A2 19A2 Item harmonics[0] % 100 YES

405029 406565 13A4 19A4 Item harmonics[1] % 100 YES

405031 406567 13A6 19A6 Item harmonics[2] % 100 YES

405033 406569 13A8 19A8 Item harmonics[3] % 100 YES

405035 406571 13AA 19AA Item harmonics[4] % 100 YES

405037 406573 13AC 19AC Item harmonics[5] % 100 YES

405039 406575 13AE 19AE Item harmonics[6] % 100 YES

405041 406577 13B0 19B0 Item harmonics[7] % 100 YES

405043 406579 13B2 19B2 Item harmonics[8] % 100 YES

405045 406581 13B4 19B4 Item harmonics[9] % 100 YES

405047 406583 13B6 19B6 Item harmonics[10] % 100 YES

405049 406585 13B8 19B8 Item harmonics[11] % 100 YES

405051 406587 13BA 19BA Item harmonics[12] % 100 YES

405053 406589 13BC 19BC Item harmonics[13] % 100 YES

405055 406591 13BE 19BE Item harmonics[14] % 100 YES

405057 406593 13C0 19C0 Item harmonics[15] % 100 YES

405059 406595 13C2 19C2 Item harmonics[16] % 100 YES

405061 406597 13C4 19C4 Item harmonics[17] % 100 YES
