Eaton Power Xpert PXR Series User Manual

59
11 Modbus register map
PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com
Register
Bit
field
Mask
field
Set point
name R/W Format Value definition UnitDEC HEX
403011 BC2 High load
alarm (Alarm1)
R/W Unsigned High Load Alarm
[50...120*] step 1
50% Ir...120% Ir
(Must be greater than High Load Warning)
* 130 for Motor protection styles
%
403012 BC3 0 0x0001 SD slp R/W Encoded Short delay slope:
0 = flat 1 = I
2
T
403013 BC4 SD pick up
(Isd)
R/W Unsigned Short delay pick up:
detail see the "PXR MCCB amp rating labels"
Isd = xxx /10 ( xIr )
*Ir
403014 BC5 SD time (tsd) R/W Unsigned long delay time:
detail see the "PXR MCCB amp rating labels"
Tsd = xxx / 1000 ( s )
ms
403015 BC6 Instan taneou s
pick up(Ii)
R/W Unsigned Instantaneous pick up:
detail see the "PXR MCCB amp rating labels"
Ii = xxx /10 ( xIn )
*In
403016 BC7 0 0x0001 Ground
sensing type
R Encoded Ground sensing type setting:
MCCB only support residual mode
0 = residual
1 = source/zero sequence
403017 BC8 0-1 0x0003 Local ground
fault type
R/W Encoded Ground fault style - trip/alarm/OFF
0 = Trip 1 = Alarm
2 = OFF
403018 BC9 0 0x0001 Ground fault
slope
R/W Encoded Ground fault slope:
0 = Flat 1 = I
2
T
403019 BCA Ground pick
up(Ig)
R/W Unsigned Ground fault pick up:
detail see the "PXR MCCB Amp Rating Labels"
Ig = xxx / 100 ( x In )
*In
403020 BCB Ground
time(tg)
R/W Unsigned Ground fault time:
detail see the "PXR MCCB amp rating labels"
Tg = xxx / 1000 ( s )
Sec
403021 BCC Ground fault
thermal
memory
R/W Thermal memory enable/disable
LD thermal memory (powered and
unpowered operation. Used only in I
2
t and I
4
t)
0 = off
1 = cooling
403022 BCD Neutral
protection
ratio
R/W Unsigned Neutral protection ratio:
0 <--> 0%
60 <--> 60%
100 <--> 100%
%
403023 BCE High load
warning
Alarm1
R/W High Load Alarm
[50...120*] step 1
50% Ir...120% Ir
(Must be less than High Load Alarm)
* 130 for Motor protection styles
403024 BCF GF_pre_alarm R/W Ground Fault trip pre alarm pick up:
*100
[50…100] step 5
403025 BD0 reserved
(TBD)
