Eaton Power Xpert PXR Series User Manual

60
11 Modbus register map
PXR TRIP UNITS FOR POWER DEFENSE MOLDED CASE CIRCUIT BREAKERS MN012007EN March 2019 www.eaton.com
Set points group 2: ModbusRTU group
Register
Bit
field
Mask
field Set points name R/W Format Value definition UnitsDEC HEX
403000 BB7 15-0 0xFFFF Password W Encoded Default “0-0-0-0”
403001 BB8 15-0 0xFFFF Group 2 = on-board Modbus R/W Encoded (Hex) 0x02FF
(Dec) 767
403002 BB9 15-0 Integrated Modbus --
communication address
R/W Encoded 001 - 246
403003 BBA 15-0 Integrated Modbus --
baudrate
R/W Encoded 00 = 9600 bit/s
01 = 19200 bit/s
02 = 38400 bit/s
03 = 57600 bit/s
403003 BBA 15-0 Integrated Modbus --
parity
R/W Encoded 00 = none
01 = odd
02 = even
403003 BBA 15-0 Integrated Modbus --
stop bit
R/W Encoded 00 = 1 bit
01 = 2 bits
Set points group 3: CAM settings group
Register
Bit
field
Mask
field Set points name R/W Format Value definitionDEC HEX
403000 BB7 15-0 0xFFFF W Encoded Default “0-0-0-0”
403001 BB8 15-0 0xFFFF R/W Encoded (Hex) 0x03FF (Dec) 1023
403002 BB9 15-0 CAM connection status R Encoded 0 = No external CAM
1 = External Modbus
2 = INCOM CAM
3 = Ethernet CAM
4 = Profibus CAM
403003 BBA 15-0 CAM communication address R Encoded 001~246 <--> 001~246
403004 BBB 15-0 CAM baud rate R Encoded 0 = 1200bps
1 = 4800bps
2 = 9600bps
3 = 19200bos
403005 BBC 15-0 CAM parity R Encoded 0 = None
1 = Odd
2 = Even
403006 BBD CAM stopbit R 0 = 1bit
1 = 2bits
403007 BBE INCOM CAM address R 0001~4094 <--> 0001~4094
403008 BBF INCOM CAM baud rate R 1 <--> 9600bps see IL01301033e
P8 "for series NRX INCOM
communication adapter module,
baud rate is fixed at 9600 baud
and represented by a value of 01"
403009 BC0 Ethernet CAM DHCP enable R 0 <--> false
1 <--> true
403010 BC1 Ethernet CAM IP addr. MSB R 0~255 <--> 0~255
403011 BC2 Ethernet CAM IP addr. LSB R 0~255 <--> 0~255
403012 BC3 Ethernet CAM IP addr. MSB R 0~255 <--> 0~255
403013 BC4 Ethernet CAM IP addr. LSB R 0~255 <--> 0~255
403014 BC5 Ethernet CAM subnet mask R 16~32 <--> 16~32
403015 BC6 Ethernet CAM default gateway R 0~255 <--> 0~255
403016 BC7 Ethernet CAM default gateway R 0~255 <--> 0~255
403017 BC8 Ethernet CAM reset pin R 0~255 <--> 0~255
403018 BC9 Profibus CAM address R 1~125 <--> 1~125
