Eaton PVM098 - EATON PVM Piston Pump Service Manual

EATON PVM Piston Pump Service Manual E-PUIO-II001-E4 December 201726
Parts Tables 1 - 8
Model PVM098
Model PVM106
EATON PVM Piston Pumps Parts Manual V-PP-TP-0001-E July 2011
38
Parts Tables 1 - 8
Model Code Position
13, 14 17, 18, 19 20, 21
All A28 00 02-346262
All A07 00 –
02 B28 11 02-346265
02 B28 24 02-346266
02 C07 24 –
02 C28 11 02-346263
02 C28 24 02-346264
04 B07 11 –
04 B07 24 –
04 B28 11 –
04 B28 24 –
04 C28 11 02-346267
04 C28 24 02-346268
Table 1 – Pressure Compensator
1
Model Code Position
9, 10 25
09 O 943305 –
10 O 943306 –
11 O 943218 –
12 O 943307 –
18 O 943308 4992727-001
19 O 943309 –
09 A-M 943310 –
10 A-M 943311 –
11 A-M 943312 –
12 A-M 943313 –
18 A-M 943314 4992727-001
19 A-M 943315 –
Table 2 – Shaft and Key
5 6
Model Code Position
11 13, 14 15, 16
E 02 00/AA/AC 943275
E 02 AB/AD 943341
E 04 00/AA/AC 943277
E 04 AB/AD 943281
F 04 00/AA/AC 943278
F 04 AB/AD 943282
G 02 00/AA/AC 943202
G 02 AB/AD 943220
G 04 00/AA/AC 943279
G 04 AB/AD 943283
H 04 00/AA/AC 943280
H 04 AB/AD 943284
Table 4 – Mounting Flange
11
Model Code Position
4, 5, 6 7, 8
098 ER 943316
098 MR 943219
098 EL 943317
098 ML 943318
106 ER 943342
106 MR 943343
106 EL 943344
106 ML 943345
Table 3 – Valve Plate
9
Model Code Position
13, 14
02 943204
04 943289
Table 5 – Housing
21
26
EATON PVM Piston Pump Service Manual
