Instruction Manual IM01005031E - rev.7
Effective December 2020
Eaton www.eaton.com 25
Eaton SPD Series for mounting external
to electrical distribution equipment
Table 6. Specifications (cont.)
Description Specification
Operating altitude Up to 16,000 ft (5000 m), (Power Xpert SPD up to 6561 ft (2000 m)
Weight Reference Figures 2 - 6 on pages 4 - 6
Form C relay contact ratings 150 Vac @ 0.46 A or 30 Vdc @ 1A, terminal block rated 300V, 16A suitable for use with 30-12 AWG
solid or stranded copper wire. Torque 5-7 lbs-in.
Form C relay contact logic Power on, normal state - NO contact = OPEN, NC contact = CLOSED Power off, fault state, - NO con-
tact = CLOSED, NC contact = OPEN
Real time clock accuracy, Power Xpert SPD Synchronized when connected to a network via an ethernet cable,
+/- 2 min/month @ 25°C when not connected to a network
EMI/RFI filtering attenuation (Standard and Standard with Surge Counter
and Power Xpert SPD)
Up to 50 dB from 10 kHz to 100 MHz
Ethernet port Data rate 10/100 Mbps, wire type: equal or exceed 5 UTP category 5, use of STP (shielded twisted
pair) will improve EMI performance. Connector type: RJ45 modular, ground metal shield
Agency certifications and approvals
Feature packages 1, 2, and 3
UL1449 4th Edition listed, CSA (excludes 230L voltage code), UL1283 7th Edition (type 2 SPDs only)
IEC 61643-11/EN 61643-11, Part 11: Test Class II. See Section 11.0 Ordering guidelines for specific
models.
Agency certifications and approvals
Feature package 4 (Power Xpert SPD)
cULus certified, UL1449 4th Edition listed, UL1283 7th Edition
IEC 61643-11/EN 61643-11, Part 11: Test Class II. See Section 11.0 Ordering guidelines for specific
models.
Warranty 10 years, 15 years if you register on www.eaton.com/spd and then click the warranty registration icon.
ROHS compliant Yes
Wire length and AWG Factory prewired with 48 inches of #10 AWG wire.
