Instruction Manual IM01005031E - rev. 7
10.0 Specifications
Table 6. Specifications (cont.)
Description Specification
Surge current capacity per phase 50, 80, 100, 120, 160, 200, 250, 300, 400 kA ratings available
Nominal discharge current (In) 20kA
Short circuit current rating (SCCR) 200kA
SPD type Basic feature package = type 1 (can also be used in type 2 applications)
Standard, Standard with Surge Counter, and Power Xpert SPD feature packages = type 2
Enclosure types NEMA 1, NEMA 4, NEMA 4X (304 SST) (Power Xpert SPD not available in NEMA 4X)
Standard split phase voltages available 120/240
Single phase 230
Three phase wye system voltages available 120/208, 127/220, 230/400, 277/480, 347/600
Three phase delta system voltages 240, 480, 600
Three phase high leg delta system voltages 120/240
Phase wire length 48” of 10AWG extend beyond the conduit hub
Relay wire length (optional) 48” of 14AWG extend beyond the conduit hub
RoHS compliant Yes
Internal disconnect (optional) Eaton 30 Amp FDC circuit breaker, type MCCB
Input power frequency 50/60 Hz, Power Xpert SPD tested to 60 Hz only
Power consumption (Basic units)
208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes
400Y and 480Y and 480D voltage codes
600Y and 600D voltage codes
0.5W
1.1W
1.3W
Power consumption (Standard and Standard with Surge Counter units
208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes
400Y, 480Y, and 480D Basic voltage codes
600Y and 600D voltage codes
0.6W
1.7W
2.1W
Power consumption (Power Xpert SPD units)
208Y, 220Y, 240S, 240D, and 240H voltage codes
400Y, 480Y, and 480D Basic voltage codes
600Y and 600D voltage codes
4W
4W
4W
Phase protection
208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes
400Y, 480Y, and 480D voltage codes
600Y and 600D voltage codes
Single split phase..L-N, L-G, N-G, L-L
Single phase .L-N, L-G, N-G
Three phase delta L-G, L-L
Three phase wye L-N, L-G, N-G, L-L
Three phase high leg delta L-N, L-G, N-G, L-L, H-N, H-G, H-L
Maximum continuous operating voltage (MCOV)
208Y, 220Y, 240S voltage codes
230L
240H
400Y and 480Y voltage codes
600Y voltage code
240 D voltage code
480 D voltage code
600D voltage code
150 L-N,300 L-G,150 N-G,300 L-L
320 L-N,640 L-G,320 N-G
150 L-N,300 L-G,150 N-G,300 L-L,320 H-N,470 H-G,470 H-L
320 L-N,640 L-G,320 N-G,640 L-L
420 L-N,420 L-G,420 N-G,840 L-L
300 L-G,300 L-L
640L- L-G, 640 L-L
840 L-G,840 L-L
Ports 1
Operating temperature -40° F to 122° F (-40°C to 50° C), Power Xpert SPD surge protection (-40°C to 50°C)
Power Xpert LCD module (-20°C to 70°C)
Operating humidity 5% through 95%, non-condensing
