TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
18
Metering Instantaneous 018 Voltage 2nd–15th
Harmonic
XX.X %
0 NA NA NA NA NA
• The values of the 2nd through 15th harmonic are displayable.
• Use the arrow keys to scroll through the 2nd through 15th harmonic.
19 Metering Instantaneous 019 Current THD
XXX.X %
0 NA NA NA NA NA
• The total harmonic distortion (THD) is displayed after entering FC 19.
• The total harmonic distortion is computed as the RSS (square root of the sum of the squares) of the individual harmonic
values.
• This is displayed as a percentage of the fundamental RMS voltage.
• Example: 200 A of 60 Hz fundamental (power line frequency), with a reading of 1.9 at the 5th harmonic (300 Hz), is 3.8 A
RMS.
19
Metering Instantaneous 019 Current 2nd–15th
Harmonic
XX.X %
0 NA NA NA NA NA
• The values of the 2nd through 15th harmonic are displayable.
• Use the arrow keys to scroll through the 2nd through 15th harmonic.
20 Metering Forward Demand 020 Forward Load
Voltage High
XXX.X Volts
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest secondary output voltage of the regulator (since last reset), as a demand value, according to the demand
time interval at FC 46.
• Date and time of the occurrence of the highest secondary output voltage is displayed.
20
Metering Forward Demand 020 Forward Load
Voltage Low
XXX.X Volts
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest secondary output voltage of the regulator (since last reset), as a demand value, according to the demand
time interval at FC 46.
• Date and time of the occurrence of the lowest load voltage is displayed.
20
Metering Forward Demand 020 Forward Load
Voltage Present
XXX.X Volts
0 NA NA NA NA NA
• This is the present reading of secondary output voltage of the regulator, as a demand value, according to the demand time
interval at FC 46
40
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
