TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
21 Metering Forward Demand 021 Fwd Compensated
Voltage High
XXX.X Volts
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the calculated secondary voltage at the center of regulation (since the last reset), as a demand
value, according to the demand time interval at FC 46.
• The forward line-drop compensation settings for resistance and reactance (FC 4 and FC 5) are used in this calculation.
• Date and time of the occurrence of the highest compensated voltage is displayed.
21
Metering Forward Demand 021 Fwd Compensated
Voltage Low
XXX.X Volts
0 NA 1 NA NA NA
• This is the lowest value of the calculated secondary voltage at the load center (since the last reset), as a demand value,
according to the demand time interval at FC 46.
• The forward line-drop compensation settings for resistance and reactance (FC 4 and FC 5) are used in this calculation.
• Date and time of the occurrence of the lowest compensated voltage is displayed.
21
Metering Forward Demand 021 Fwd Compensated
Voltage Present
XXX.X Volts
0 NA NA NA NA NA
• This is the present value of the calculated secondary output voltage of the load center, as a demand value, according to the
demand time interval at FC 46.
• The forward line-drop compensation settings for resistance and reactance (FC 4 and FC 5) are used in this calculation.
22 Metering Forward Demand 022 Forward Load
Current High
XXX.X A
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the load current (since last reset), as a demand value, according to the demand time interval at
FC 46.
• Date and time of the occurrence of the highest load current is displayed.
22
Metering Forward Demand 022 Forward Load
Current Low
XXX.X A
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the load current (since last reset), as a demand value, according to the demand time interval at
FC 46.
• Date and time of the occurrence of the lowest load current is displayed.
22
Metering Forward Demand 022 Forward Load
Current Present
XXX.X A
0 NA NA NA NA NA
• This is the present reading of the load current as a demand value, according to the demand time interval at FC 46.
41
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
