TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level
Factory
Setting
Key Entry Limit
Read Edit Reset Low High
160 Features Communications
Protocol
160 Com Port #2
DNP
0 2 NA DNP NA NA
• This function defines which resident protocol of the control will be used on Communications Port #2; options include:
• DNP •2179
• See the Control Features: Digital SCADA section of this manual.
161 Features Communications 161 Com Port #2
Speed
9600 BPS
0 2 NA 9600 NA NA
• The control microprocessor has two communications channels, each with selectable baud rates.
• Options for Communications Port #2 include:
• 300 • 600 • 1200 • 2400
• 4800 • 9600 • 19200 • 38400
162 Features Communications 162 Com Port #2
Sync Time
0 msec
0 2 NA 0 0 65535
• This defines the period of time, for Com Port #2, the received data line must idle to assume the start of a request
message.
• See the Control Features: Digital SCADA section of this manual.
163 Features Communications 163 Com Port #2
DNP Master Adrs
1234
0 2 NA 1234 0 65535
• The control will send unsolicited responses to this master address.
164 Features Communications 164 Com Port #2
DNP Remote Adrs1
2
0 2 NA 2 0 65535
• This is the primary DNP remote address for Com Port #2.
• The DNP Remote Address 1 for Com Port #2 is entered at FC 64 with a factory preset address of 2.
164
Features Communications 164 Com Port #2
DNP Remote Adrs2
65519
0 2 NA 65519 0 65535
• This is the DNP remote address available for remote configuration. For more information, contact your Eaton
representative.
• The DNP Remote Address 2 for Com Port #2 is entered at FC 64 with a factory preset address of 65519.
164
Features Communications 164 Com Port #2
2179 Remote Adrs
6
0 2 NA 6 0 2046
• This is the control SCADA 2179 Remote Address for Com Port #2.
• Each control on the system can be uniquely addressed by the SCADA RTU or other communications device. For 2179, the
options include:
• 0-2046 = Unique device address range. Controls with addresses in this range uniquely respond when the particular address is
sent.
• All controls on the system listen and change as commanded, with no response, if a message is sent to address 2047.
• The control SCADA address for Com Port #1 is entered at FC 64 with a factory preset address of 6.
• For 2179, the High Entry Limit is 2046.
62
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
