TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level
Factory
Setting
Key Entry Limit
Read Edit Reset Low High
142 Counters Menu System 142 Date Format
MM/DD/YYYY
0 2 NA MM/DD/ NA NA
• This setting allows the user to select how the date format will be displayed. Options include:
• MM/DD/YYYY • DD/MM/YYYY • YYYY/MM/DD
143 Counters Menu System 143 Time Format
12 Hour AM/PM
0 2 NA 12
Hour
NA NA
• This setting allows the user to select whether time will be displayed on the 12-hour or the 24-hour scale. Options include:
• 12 Hour AM/PM • 24 Hour
144 Settings Configuration 144 P.I. ADD-AMP
High Limit
16
0 2 NA 16 NA NA
• The physical location of the high P.I. limit of the position indicator, as set by the user, is entered by the user-operator here.
• The allowable values are 16, 14, 12, 10, or 8.
145 Settings Configuration 145 P.I. ADD-AMP
Low Limit
-16
0 2 NA -16 NA NA
• The physical location of the low P.I. limit of the position indicator, as set by the user, is entered by the user-operator here.
• The allowable values are -16, -14, -12, -10, or -8.
146 Settings Configuration 146 Vin P.T.
Configuration
Vdiff Mode
0 2 NA Vdiff
Mode
NA NA
• This defines the configuration of the PT for the source-side voltage. Options include:
• V
diff
Mode • V
in
Mode.
• The V
diff
Mode is used when the regulator is provided with an internal differential PT or if the Source Voltage Calculator (FC
39) is turned on. The V
in
Mode is selected when an external source PT is supplied by the user to provide the source voltage
for the CL-6 control.
• See the Control Features: Source-Side Voltage section of this manual.
150 Features Calibration 150 Reset
Calibration
0 3 NA NA NA NA
• This is a command. When Enter key is pressed, a (CONFIRM) message is displayed on the fourth line of LCD. When Enter
key is pressed again, voltage and current calibration factors are reset.
151 Settings Calendar Clock 151 Daylight Savings
Time Enable
Off
0 3 NA Off NA NA
• This function enables daylight savings time to function. Options include:
• Off • On
152 Settings Calendar Clock 152 Daylight Savings
Time Active
No
0 NA NA NA NA NA
• This function displays if daylight savings time is currently active (Yes or No).
