TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
125
Metering Instantaneous 125 Energy kW-hour
Reverse
XXXX.X kW-h
0 NA 1 See
Note
NA NA
• This is the total reverse energy, measured in kilowatt hours.
• Note: This is reset to zero by pressing Edit/Reset, then Enter, and when the Date/Time is changed.
126 Metering Instantaneous 126 Energy kvar-hour
Forward
XXXX.X kvar-h
0 NA 1 NA NA NA
• This is the total forward energy, measured in kvar.
126
Metering Instantaneous 126 Energy kvar-hour
Reverse
XXXX.X kvar-h
0 NA 1 NA NA NA
• This is the total reverse energy, measured in kvar.
127 Metering Forward Demand 127 Maximum % Boost
XX.X %
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest percentage that the regulator has raised the input voltage (since last reset).
• This parameter is the upper drag-hand value for the present percent regulation, FC 12.
• The control requires an input voltage from a differential or source potential transformer to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
128 Metering Forward Demand 128 Maximum % Buck
XX.X %
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest percentage that the regulator has lowered the input voltage (since last reset).
• This parameter is the lower drag-hand value for the present percent regulation, FC 12.
• The control requires an input voltage from a differential or source potential transformer to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
140 Settings Configuration 140 Regulator Type
Type B
0 2 NA See
Note
NA NA
• Regulator type defines the regulator type based on ANSI standards. Options include:
• Type A (series design)
• Type B (inverted design)
• Type C (series transformer design) Series TX is listed on nameplate. Used on Eaton voltage regulators with voltage rating of
2.5 kV and current ratings above 875 A.
• Type D (series auto transformer design) Series AX is listed on nameplate. Used on Eaton voltage regulators with voltage
rating of 5.0 kV and 7.62 kV and current rating above 875 A.
• Note: The regulator type is included on nameplates.
141 Settings Menu System 141 Language
Selection
English
0 2 NA English NA NA
• This setting allows the user to select the language to display. Options include:
• English • Spanish • French • Portuguese
60
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
