TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
103 Counters Operations
Counter
103 Current Month
Operations
XXXXX
(Date / Time shown)
0 NA 3 See Note NA NA
• Operations since the beginning of current month (updated on every tap change and reset when the clock’s month
changes).
• Note: This is reset to zero by pressing Edit/Reset, then Enter.
104 Counters Operations
Counter
104 Last Month
Operations
XXXXX
(Date / Time shown)
0 NA 3 See Note NA NA
• Operations in last calendar month (if reset, this field will remain zero until the month changes).
• Note: This is reset to zero by pressing Edit/Reset, then Enter.
105 Counters Operations
Counter
105 Current Year
Operations
XXXXX
(Date / Time shown)
0 NA 3 See Note NA NA
• Operations since January 1st of current year (updated on every tap change and reset when the clock’s year changes).
• Note: This is reset to zero by pressing Edit/Reset, then Enter.
106 Counters Operations
Counter
106 Last Year
Operations
XXXXX
(Date / Time shown)
0 NA 3 See Note NA NA
• Operations in last calendar year (if reset, this field will remain zero until the year changes).
• Note: This is reset to zero by pressing Edit/Reset, then Enter.
107 Counters
Counter
Operations 107 Enable Interval
Counters
Enabled
0 3 NA Enabled NA NA
• FC 107 is used for enabling FC 101 to FC 106. Options include:
• Enabled • Disabled
112 Metering Instantaneous 112 Percent
Regulation
XX.X %
0 NA NA NA NA NA
• When the regulator output voltage is greater than the input voltage (regulator boosting), the sign is implied (+). When the
output voltage is lower than the input voltage, the sign is implied (-).
• This is the actual percentage that the regulator is actively boosting (raising) or bucking (lowering) the input (source)
voltage.
• Tap position indication is calculated as follows: % regulation = [(output÷input) - 1] x 100.
• During reverse power operation, the control requires source voltage from a differential or source potential transformer or from
the source voltage calculation (see FC 39) to obtain this parameter. Lack of this voltage will result in the parameter displaying
dashes.
125 Metering Instantaneous 125 Energy kW-hour
Forward
XXXX.X kW-h
0 NA 1 See Note NA NA
• This is the total forward energy, measured in kilowatt hours.
• Note: This is reset to zero by pressing Edit/Reset, then Enter, and when the Date/Time is changed.
59
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
