TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
97 Features Security
Access
097 Security Code
Level 2
12121
3 3 NA 12121 10000 19999
• The number to be used as the level 2 security code is entered here.
• Entry of this number at FC 99 permits the user to change/reset only the parameters marked as level 2 security (control
settings, configuration, and clock) and level 1 security (demand and tap positions readings).
• See the Control Operation: Security System section of this manual.
98 Features Security
Access
098 Security Code
Level 3
32123
3 3 NA 32123 20000 32766
• The number to be used as the level 3 security code is entered here.
• Entry of this number at FC 99 permits the user to change/reset any parameter.
• Note: If the level 3 code is changed by the user, the new value should be recorded and kept in a safe place. If lost, the
security codes can be retrieved with a flash card and CCI software, with the CCI software via a PC directly connected to the
control, or with the remote communications system.
• See the Control Operation: Security System section of this manual.
99 Features Security
Access
Security Code
_____
3 3 NA 32123 20000 32766
• This is the function code used to access the menu location where security codes are entered for access to the system.
• Scrolling to this level is not allowed.
• See the Control Operation: Security System section of this manual.
100 Counters Operations
Counter
100 Last Counter
Change
XXXXX
(Date / Time shown)
0 NA NA NA NA NA
• FC 100 displays the time and date since the last total-operations counter change, as well as the quantity of operations since
the last change.
• The function code may be set to a specific value.
101 Counters Operations
Counter
101 Last 24 Hours
Operations
XXXXX
(Date / Time shown)
0 NA 3 See
Note
NA NA
• Operations in last 24 hours (updated hourly and on every tap change).
• Note: This is reset to zero by pressing Edit/Reset, then Enter.
102 Counters Operations
Counter
102 Last 30 Days
Operations
XXXXX
(Date / Time shown)
0 NA 3 See
Note
NA NA
• Operations in last 30 days (updated daily and on every tap change).
• Note: This is reset to zero by pressing Edit/Reset, then Enter.
58
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
