Do not attempt to utilize standard 20A or 32A powerCON™ connectors. They
will not fit and may damage the module, and/or cause injury to the user.
Mains power is supplied to each PDU via an L21-30 (US) or CEEform 32A
(International) connector.
ADAPTive electronics modules will operate on voltages ranging from 90 to
265V AC, 50/60 Hz. No module setting changes are necessary to switch
between regional voltage ranges (120, 208, 220, etc.)
As with data, ADAPTive systems include pre-defined AC power cable
assemblies with tails and extensions, based around 6-module fan-out looms
of varying lengths, as well as extenders. This system supports a variety of
array lengths:
# of Modules
(per column)
Loom Extension
To Next Page
