Drawings KF852E
DIMENSIONAL DRAWINGS INPUT PLATES
KF852EP
ALL DIMENSIONS ARE IN INCHES UNLESS OTHERWISE NOTED
13.00
BOTTOM
SIDES
2.00
29.50
35.50
BACK
16.50
21.88
5.38
2.35
8.25
20.90
5.00
2.38
2.63
38.00
2.00
1.88
13.58
5.00
2.63
26.38
FRONT
TOP
9.5°
42.00
MOUNTING POINTS 3/8"-16 NUTS WELDED TO A 2"x 2" STEEL PLATE
KF852EF

35.50
13.00
3.91
29.91
NOTE:
MOUNTING POINTS 
ARE RECESSED 
MULTI- POINT AIR-
CRAFT SEAT FLY 
TRACK ATTACHED 
VERTICALLY AND 
HORIZONTALLY TO 
THE CABINET'S 
ALUMINUM INTERNAL 
STRUCTURAL BRACES.
19.00
BOTTOM
7.00
BACK
SIDES
2.25
29.50
16.50
29.50
FRONT
26.38
TOP
9.5°
42.00



-- +
MID 1 MID 2 HIGH
-- --++
KF-852EP
NO.
MADE IN USA
EASTERN ACOUSTIC WORKS
Virtual Array
TM
TECHNOLOGY
PIN 5 PIN 6
HIGH HIGH
... ...
--
+
PIN 3 PIN 4
MID MID
... ...
--
+
PIN 1 PIN 2
LOW LOW
... ...
--
+
KF-852EF
NO.
MADE IN USA
EASTERN ACOUSTIC WORKS
Virtual Array
TM
TECHNOLOGY
CANNON
1 2
3
4 5
6
CANNON
1 2
3
4 5
6
