EBA 550LT - Clamp Plate and Air Table Features

- 14 -
EBA 550 • EBA 550 LT
A
B
A
B
A
• Operation •
Clamp plate:
A clamp plate (A) is fitted to the machine to
prevent pressure marks on sensitive material.
To dismantle:
• Remove the clamp plate (A) by turning the
screwdriver (found in tool box) in the space
between the clamp and clamp plate.
 The remaining cut is 3,2 cm.
To mount:
• The clamp plate (A) is inserted to the top
into the clamp (B).
 The remaining cut is 6 cm.
Air table
It is easier to position large stacks of paper
when the airtable (A) is switched on.
