- 26 -
EBA 550 • EBA 550 LT
• Blade and cutting stick replacement •
• Set mains switch (A) to position "I" .
• Set clamping oil pressure (B) to min. 50 bar.
• Press in blade locking key (C).
• Activate cutting blade remains in lowest
position.
• Set mains switch to position "0".
Remove the left screw (D), using the
extension.
Pull out blade locking key blade moves to
the top.
A
C
B
D
