- 36 -
EBA 550 • EBA 550 LT
B
A
• Maintenance and cleaning •
Maintenance work may only be performed
by trained staff.
Danger!
Disconnect the mains before starting
any service work or before removing the
cover.
Grease and oil the machine according to
the lubrication diagram after 1000 operating
hours or once a year. If the machine is
subject to excessive load then twice a year.
The hydraulic oil must be changed every
2000 operating hours or every 2 years.
Type of oil:
Aral Vitam DE 46 to DIN 51562. Volume:
approximately 7 litres.
(A) Drain screw
(B) Oil stick
• Check that the hydraulic pump and screws
are not leaking. If necessary tighten the
retaining nut.
• Check pressure. Maximum pressure is
150 bar.
