Chengdu Ebyte Electronic Technology Co., Ltd. E22-900T22D User Manual
Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co.,Ltd.
When defined as a transmitting party, a preamble is automatically added before transmitting.
It can receive data normally, the receiving function is the same as mode 0.
6.4 Configuration mode（Mode 2）
Wireless transmitting off
Users can access the registers to configure the module's operation state.
6.5 Deep sleep mode（Mode 3）
Unable to transmit wireless data
Unable to receive wireless data
When from the sleep mode to other modes, the module will reconfigure the parameters. During the configuration process,
AUX will remain low; After configuration,it outputs high level, we suggest that user test rising edge AUX.
7 Register read and write control
7.1 Command format
In configuration mode (mode 2: M1 = 1, M0 = 0), the list of supported commands are as follows (only 9600, 8N1 format is
supported when)
：
Command: C0+starting address+length+parameters
Response: C1+starting address+length+parameters
E.g 1: Channel is 0x09
command starting address length parameter
Send: C0 05 01 09
