Ebyte E22 Series User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. E22-900T22D User Manual
Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co.,Ltd.
16
03H
Read/Wr
ite
REG0
7，6，5 UART: Serial port rate（bps）
000: 1200
001: 2400
010: 4800
011: 9600（default）
100: 19200
101: 38400
110: 57600
111: 115200
---------------------------------------
4，3： Serial parity bit
00：8N1（default）
01
：
8O1
10：8E1
11
：
8N1
（
equal to 00
）
-----------------------------------
2，1，0，air data rate
000: 0.3k
001: 1.2k
010: 2.4k（default）
011: 4.8k
100: 9.6k
101: 19.2k
110: 38.4k
111: 62.5k
 For the two modules that communicate with each
other, the serial port baud rate can be different, and
the verification method can also be different.
 When transmitting large packets continuously, users
need to consider the data blocking caused by the
same baud rate, and data may even be lost. It is
generally recommended that both parties have the
same baud rate.
---------------------------------------
 Both parties must be the same
 The higher the rate, the shorter the distance
04H
Read/Wr
ite
REG1
7，6： Sub packet setting
00: 240 bytes
（
default
）
01: 128 bytes
10: 64 bytes
11: 32 bytes
--------------------------------------
5 ：RSSI Ambient noise enable
1: Enable
0: Disable（default）
--------------------------------------
4，3，2 Reserve
--------------------------------------
1
，
0
：
Transmitting power
00
：
22dbm
（
default
）
01：17dbm
10
：
13dbm
11
：
10dbm

When the data is smaller than the sub packet length,
the serial output of the receiving end is an
uninterrupted continuous output.
When the data is larger than the sub packet length,
the receiving end serial port will output the sub
packet.
--------------------------------------------

When enabled, the C0 C1 C2 C3 command can be
sent in the transmitting mode or WOR transmitting
mode to read the register.
Register 0x00: Current ambient noise rssi
Register 0X01: rssi when the data was received last
time.
（Current channel noise is: dBm = -（256 - RSSI））
Command format: C0 C1 C2 C3 + starting address +
read length
Returns: C1 + address address + read length + read valid
value
E.g: send C0 C1 C2 C3 00 01
Return C1 00 01 rssi
----------------------------------

Power and current are nonlinear, and power
efficiency is highest at maximum power.
 The current does not decrease in proportion to the
decrease in power.
05H
Read/Wr
ite
REG2
Channel control（CH）
0-80 represents a total of 81 channels
 Frequency= 850.125 + CH *1M
