 The hermetic flue set is delivered in a carton box separate from the unit. The standard hermetic flue set

(Ø 60/100 or Ø 80/125) consists of the following components (Figure 5).

Figure 2: Flue Kit

FLUE PACKAGE LIST

1. 90° C Elbow

6. Flange Screws

2. Exhaust Gas Tap

7. Flange Gaskets

3. Air Inlet Tap

8. Flue Exhaust Terminal

4. Sealing Gasket Ø60 or Ø80

9. Inner Wall Connection Flange

5. Sealing Gasket Ø 100 or Ø125

10. Outer Wall Connection Flange (EPDM)

Table 5: Flue Package List

Figure 3: Isolating Valve Kit

VALVE KIT PACKAGE LIST

1. Valve Fixing Bracket (1pc)

5. DHW inlet Valve (1pc)

2. CH Supply Manifold Valve (1pc)

6. CH Return Manifold Valve (1pc)

3. DHW Outlet Manifold Valve (Elbow) (1pc)

7. Wras Approved Filling Loop (1 pc)

4. Gas Manifold Valve (1pc)

8. Isolating Valve Kit

Table 6:Valve Kit Package List

1 2 3 4 5 6 7
