6.4 Technical Data
Specifications
Unit
Proteus Premix
24 HM-HCH-HST
Proteus Premix
30 HM-HCH-HST
Proteus Premix
35 HM-HCH-HST
Gas Category
I2H, I3P, I2Esi, I2E(S), II2L3P, II2L3B/P, II2H3P,
II2H3B/P, II2ELL3B/P, II2Esi3P
Flue Types
C13(X), C33(X)
Gas Input Pressure (G20)
mbar
20
Gas Input Pressure (LPG G31)
mbar
37/50
Gas Input Pressure (LPG G30)
mbar
30
Capacity-Efficiency
Min. Heating power - (@60°C min)
kW
5,6
6,9
8
Max. Heating power - (@80/60°C)
kW
24,5
30
35
Min. Heating power - (@30°C min)
kW
6,7
8,3
9,6
Max. Heating power- (@50/30°C)
kW
26
31,7
37
Min. Heat input
kW
6,2
7,7
9
Max. Heat input
kW
25,2
30,8
35,9
Efficiecny (@80°/60° C Max)
97,50%
Efficiecny (30°C Return)
107,50%
ERP Informations
Seasonal Space Heating Energy
Efficiency Class
A
A
A
Water Heating Energy Efficiency
Class/ Load Profile (Only HM)
A/XL
A/XL
A/XL
Rated Heat Output (Prated)
kW
24,5
30
35
Seasonal Space Heating Energy
Efficiency
%
92,2
92
92,9
Water Heating Energy Efficiency
(Only HM)
%
83,6
82,8
82,8
Sound Power Level
db(A)
49
Emissions of Nox Level
mg/kWh
< 56
Gas Consumption
Natural Gas (@Min-Max Capactiy)
m3/h
0,65-2,65
0,81-3,25
0,94-3,79
Propan (@Min-Max capacity)
kg/h
0,51-1,98
0,63-2,46
0,74-2,87
NOX Class
6
Central Heating
Min. Water Pressure
bar
0,4
Max. Water Pressure (PMS)
bar
2,5
Operation Range (@Radiator
heating)
° C
30-80*
Operation Range (@Underfloor
heating)
° C
30-45*
Max. Limit temperature
° C
> 90
DHW (HM model)
Min. Domestic flow for operating
L/min
2 (±%10)
Min. Domestic flow for closing
L/min
1,5 (±%10)**
Max. Domestic hot water flow rate
L/min
10 ±%15 (ΔT
= 34,7°C)
12 ±%15 (ΔT =
35,8°C)
14 ±%15 (ΔT =
35,8°C)
Kitchen specific flow rate
L/min
8,8 ±%15 (ΔT
= 40°C)
10,8 ±%15 (ΔT =
40°C)
12,5 ±%15 (ΔT =
40°C)
