Level Mode Flash Patterns
Order Flash Pattern - Module Group
1 Fast In-Out Quad - Front/Rear
2 Picket Fence Single - Front/Rear
3 In-Out Single - Front/Rear
4 Picket Fence Quad - Front/Rear
5 Picket Fence Six - Front/Rear
6 Slow In-Out Quad - Front/Rear
7 Slow In-Out Six - Front/Rear
8 Fast In-Out Six - Front/Rear
9 Variable Rate Picket Fence Single - Front/Rear
10 In-Out Quad - Front/Rear
11 Cycle - Front/Rear
12 Simulataneous Quad - Front/Rear
13 Fast In-Out Quad - Rear
14 Picket Fence Single - Rear
15 In-Out Single - Rear
16 Picket Fence Quad - Rear
17 PIcet Fence Six - Rear
18 Slow In-Out Quad - Rear
19 Slow In-Out Six - Rear
20 Fast In-Out Six - Rear
21 Variable Rate Picket Fence Single - Rear
22 In-Out Quad - Rear
23 Cycle - Rear
24 Simultaneous Quad - Rear
25 Fast In-Out Quad - Front
26 Picket Fence Single - Front
27 In-Out Single - Front
28 Picket Fence Quad - Front
29 Picket Fence Six - Front
30 Slow In-Out Quad - Front
31 Slow In-Out Six - Front
32 Fast In-Out Six - Front
33 Variable Rate Picket Fence Single - Front
34 In-Out Quad - Front
35 Cycle - Front
36 Simultaneous Quad - Front
For instructions related to the California Title 13 steady burning red warning lamp requirement during level mode operation, please contact
ECCO directly.
TABLE 16
