Ecco 65S - Nozzle Sets; Nozzle Sets and Nozzle Combinations

Nozzle set Air cap Paint nozzle Orifice dia Capacity Paint needle
Part number Designation Designation Designation mm ml/min Designation
6003 9232 09 6509-01 6509 G 0.9 0.9 90–200 P007
6003 9235 11 6511-01 6511 HVLP 11 1.1 150–225 P007
6003 9237 14 6514-01 6514 HVLP 14 1.4 200–270 P07
6003 9239 18 6518-01 6518 HVLP 18 1.8 200–350 P07
6003 9242 21 6521-01 6521 HVLP 21 2.1 250–400 P07
6003 9246 27 6527-01 6527 HVLP 27 2.7 250–400 P07
Nozzle sets
Consists of air cap, paint nozzle of stainless steel
and paint needle of nylon.
a
The letter “P“ before the designation denotes nylon design.
b
Fluid needle with cylindrical point (self-cleaning tip).
c
The letter “H“ before the designation denotes tungsten-carbide design tip.
d
The letter “H“ before the figures (e.g., H1.4 ) denotes tungsten-carbide design.
e
Acetal plastic retaining ring.
Nozzle combinations
07 6000 9275 00
H07
c
6000 9881 00
6514 6003 9237 00
T6578 6003 9578 00
T6578 6003 9579 00
e
07 6000 9275 00
H07
c
6000 9881 00
6518 6003 9239 00
P07 6001 1471 00 6527 6003 9246 00
6521 6003 9242 00
4
07 6000 9275 00
H07
c
6000 9881 00
07 6000 9275 00
H07
c
6000 9881 00
1807
b
6101 3848 80
Paint nozzle Paint needle Air cap
Stainless steel Nylon
Orifice
diameter Designation Part number Designation Part number Designation Part number Designation Part number
mm (a)
0.6 G0.6 6003 9206 00
0.8 G0.8 6003 9208 00 007 6001 0548 00 P007 6101 5747 00 6509 6003 9232 00
0.9 G0.9 6003 9209 00
1.1 G1.1 6003 9211 00 007 6001 0548 00 P007 6101 5747 00 6511 6003 9235 00
1.2 G1.2 6003 9212 00 P07 6001 1471 00
1.4 G1.4 6003 9214 00 07 6000 9275 00 P07 6001 1471 00
1.4 G1.4
d
6003 9650 14 H07
c
6000 9881 00 P1307
b
6101 5982 00
1.6 G1.6 6003 9216 00 P07 6001 1471 00
1.8 G1.8 6003 9218 00 P P07 6001 1471 00
1.8 G1.8
d
6003 9650 18 P1807
b
6101 3844 00
2.1 G2.1 6003 9221 00 P07 6001 1471 00
2.1 G2.1
d
6003 9650 21 P2107
b
6003 9366 00
07 6000 9275 00
H07
c
6000 9881 00
2.7 G2.7 6003 9227 00
