ECG tb6560 User Manual

The 3
rd
Generation TB6560 Stepper Driver Set
-
-
-
-
S
S
A
A
V
V
E
E
B
B
A
A
S
S
E
E
Email: ebay@savebase.com Web: http://stores.ebay.co.uk/SAVEBASE 19
Professional Models
TB3-P
3 Axis Driver○P
 Intelligently Control Motors Via PC
TB3CD-P
3 Axis Driver○P
+ Control Pad○P
+ Display Panel
 Intelligently Control Motors Via PC
 Manually Control Motors Via Control Pad
 Intelligently Switch PC & Control Pad
 Real-time Display the moving path of motors
 Record G-Code from PC and run it without PC
 Manually Program and run it to control Motors
TB4-P
3 Axis Driver○P
 Intelligently Control Motors Via PC
TB4CD-P
4 Axis Driver○P
+ Control Pad○P
+ Display Panel
 Control Motors Via Control Pad
 Intelligently Switch PC & Control Pad
 Real-time Display the moving path of motors
 Record G-Code from PC and run it without PC
 Manually Program and run it to control Motors
TB3-P(Box)
3 Axis Driver○P
(Box)
 Intelligently Control Motors Via PC
 Aluminum Box Protection
TB4-P(Box)
4 Axis Driver○P
(Box)
 Intelligently Control Motors Via PC
 Aluminum Box Protection
TB3C-P(Box)
3 Axis Driver○P
+ Control Pad○P
(Box)
 Intelligently Control Motors Via PC
 Manually Control Motors via Control Pad
 Intelligently Switch PC & Control Pad
 Aluminum Box Protection
TB4C-P(Box)
4 Axis Driver○P
+ Control Pad○P
(Box)
 Intelligently Control Motors Via PC
 Manually Control Motors via Control Pad
 Intelligently Switch PC & Control Pad
 Aluminum Box Protection
TB3CD-P(Box)
3 Axis Driver○P
+ Control Pad○P
+ Display Panel
(Box)
 Intelligently Control Motors Via PC
 Manually Control Motors Via Control Pad
 Intelligently Switch PC & Control Pad
 Real-time Display the moving path of motors
 Record G-Code from PC and run it without PC
 Manually Program and run it to control Motors
 Aluminum Box Protection
TB4CD-P(Box)
4 Axis Driver○P
+ Control Pad○P
+ Display Panel
(Box)
 Intelligently Control Motors Via PC
 Manually Control Motors Via Control Pad
 Intelligently Switch PC & Control Pad
 synchronously display the Moving coordinate
 Real-time Display the moving path of motors
 Record G-Code from PC and run it without PC
 Manually Program and run it to control Motors
 Aluminum Box Protection
