ECG tb6560 User Manual

The 3
rd
Generation TB6560 Stepper Driver Set
-
-
-
-
S
S
A
A
V
V
E
E
B
B
A
A
S
S
E
E
Email: ebay@savebase.com Web: http://stores.ebay.co.uk/SAVEBASE 3
 1, 2, 8, 16 adjustable microstep control, motors run more precisely and smoothly.
 Overload, overcurrent, overvoltage, overheat protection to avoid damaging your computer and devices.
 Totally enclosed optical isolation and bipolar constant-current chopper to insure motors work at low noise & vibration, and
avoid motors creep at a low speed.
 With one 0-10V PWM Signal output port for speed adjustment and one Relay control port.
 5 types of input control in manual control interface, to set Limit, Estop, Midpoint-Setting, Cutter-presetting/Tool-Setting
etc...
III. Applications
Suitable for a wide range of 2-phase and 4-phase hybrid stepping motors, from NEMA size 17 to 34. It can be used in various
kinds of machines, such as X-Y tables, labeling machines, laser cutters, engraving machines, pick-place devices, and so on.
Particularly adapt to the applications desired with low noise, low heating, and high speed performance.
2. Specifications
I. Electrical Specifications (Tj = 25℃/77℉)
Input voltage
12V-36V DC
Output current
0.5A-3.5A (Peak)
Drive type
Pulse + Direction + Enable Signal Control (Bipolar constant-current PWM output)
Suitable motor
Nema17, Nema23, Nema24, Nema34 (Rated current: 0.5A-3.5A)
Net weight
390g (Driver)
Dimensions
174*142*38mm
II. Operating Environment and other Specifications
Cooling
Natural Cooling or Fan Forced cooling
Operating Environment
Environment
Avoid dust, oil fog and corrosive gases
Ambient Temperature
0 ℃－ 50℃ (32℉ － 122℉)
Humidity
40%RH － 90%RH
Operating Temperature
70℃ (158℉) Max
Storage Temperature
-20 ℃ － 65℃ (-4℉ － 149℉)
Total Weight
Approx. 620g (Driver + Control Pad + Display Panel)
