42
through 【▲】and【▼】button. After selecting the setting item, use and button to
choose setting contents
There are 6 display formats as following: 3×4, 3×4+1R, 3×4+3R, 6×2, 6×2+1R and 12×1.
3×4 12 leads ECG waveform display with 3rows ×4 columns
3×4+1R 12 leads ECG waveform display with 3rows ×4 columns+ 1 rhythm lead
3×4+3R 12 leads ECG waveform display with 3 rows×4 columns+ 3 rhythm leads
6×2 12 leads ECG waveform display with 6 rows×2 columns
6×2+1R 12 leads ECG waveform display with 6 rows×2 columns+1 rhythm lead
12×1 12 leads ECG waveform display with 12 rows×1 column
Display sequence: sequential mode or simultaneous mode. In sequential mode, the waveforms
will be displayed one group after another group. In simultaneous mode, all waveforms will be
displayed at the same time. After display setup finished, press 【F1】 button to save and return,
or press 【F2】 button to cancel setup and return.
5.9 System Setting
On the first page of the main interface, press 【F6】 to enter system setup interface. The interface is
shown as the figure below:
Press 【F1】 button to save system setting and return, press 【F3】 button to cancel setting and
return, or press 【F2】 button to return to the default setup. Press button 【1】～【9】to enter different
items settings menu:
