Echo CS-280E

REMARKSDESCRIPTIONQTYPART NUMBERITEM
Screw4125344139301
Cover, diaphragm1125342139302
Included in Repair Kit P/N 12530015130 & Gasket,
Diaphragm Kit P/N 12530115130
Diaphragm13
Included in Repair Kit P/N 12530015130 & Gasket,
Diaphragm Kit P/N 12530115130
Gasket, diaphragm14
Disk1125375139305
Included in Repair Kit P/N 12530015130Valve arm16
Included in Repair Kit P/N 12530015130Arm pin17
Included in Repair Kit P/N 12530015130Needle valve18
Included in Repair Kit P/N 12530015130Coil spring19
Screw11253391393010
Included in Repair Kit P/N 12530015130Orifice, main fuel11253761393011
Clip11253271393012
Includes item 14Coil spring21253191393013
Included in Coil spring item 1314
Needle, high speed11253201393015
Needle, idle11253181393016
Return spring11253131393017
Throttle shaft11253171393018
Throttle shutter11253161393019
Included in Repair Kit P/N 12530015130Screw120
Included in Repair Kit P/N 12530015130Screen121
Included in Repair Kit P/N 12530015130 & Gasket,
Diaphragm Kit P/N 12530115130
Diaphragm, fuel pump122
Included in Repair Kit P/N 12530015130 & Gasket,
Diaphragm Kit P/N 12530115130
Gasket. fuel pump123
Pump cover11253241393124
Screw, idle adjustment11253341393025
Screw11253101393026
Screw11253481393027
Throttle lever11253501393128
Friction piece11253781393029
Welsh Plug11253451393031
Included in Repair Kit P/N 12530015130 & Gasket,
Diaphragm Kit P/N 12530115130
Diaphragm, surge132
Includes items 3, 4, 6, 7, 8, 9, 20, 21, 22, 23 & 32Repair Kit12530015130
Includes items 3, 4, 22, 23 & 32Gasket, Diaphragm Kit12530115130
99922203922_C - 5 - REVISED 01/23/07
Table of Contents Part Number Index
CS-280E CHAIN SAW Carburetor
