CS-310 DESCRIPTION
© 08/2013 ECHO Inc.
X7503270007 17
5. Pull the chain around the bar by hand. Loosen the adjustment if
you feel tight spots.
Tighten guide bar nuts to 4.5 – 7.5 N•m (40 – 65 in•lbf) DO NOT
over-tighten nuts. Damage to saw may result.
6. Keep chain properly tensioned at all times.
Note: All chains require frequent adjustments.
7. Replace spark plug lead and air cleaner cover.

Echo CS-310 Specifications

General

Engine Displacement	30.5 cc
Bar Length	14 inches
Weight	8.8 lbs
Chain Pitch	3/8 inch
Chain Gauge	0.050 inch
