38 X7503251406
© 08/2013 ECHO Inc.
TECHNICAL DATA CS-370
TECHNICAL DATA
* Technical data subject to change without notice.
Model CS-370
Length 393 mm (15.5 in.)
Width 245 mm (9.6 in.)
Height 277 mm (10.9 in.)
Dry weight 4.5 kg (10.0 lb.) Without chain and guide bar
Engine Air-cooled two-stroke single cylinder
Displacement 36.3 mL (2.213 cu. in.)
Bore 38.0 mm (1.496 in.)
Stroke 32.0 mm (1.259 in.)
Compressions ratio 7.3 : 1
Carburetor Diaphragm type
Spark plug NGK BPM8Y
Fuel tank capacity 410 mL (13.9 US. fl. oz.)
Fuel
50 : 1 ratio with ECHO Power Blend X™, ISO-L-EGD (ISO/CD 13738) and JASO
M345-FD two-stroke, air-cooled engine oil.
Gasoline
Use 89 octane unleaded. Do not use fuel containing methyl alcohol, more than 10 %
ethyl alcohol or 15 % MTBE. Do not use alternative fuels such as E-15 or E-85.
Oiling system Adjustable automatic oiler
Chain oil capacity 280 mL (9.5 US. fl. oz.)
Starter system Automatic rewind starter
Clutch Centrifugal type
Sprocket type Spur type, 6-tooth, 3/8 in. pitch
Chain brake Automatic band brake type
Idle speed 2,650 RPM
Clutch engagement speed 4,050 RPM
Wide open throttle speed
(W.O.T.)
12,500 RPM
Chain tensioner Side access system
Guide bar 14, 16, 18 in
Saw chain 91PX/91VG
Standard features
Front hand guard, Rear hand guard, Anti-vibration device, Spiked bumper, Throttle
control lockout, Chain catcher, Spark arrestor muffler, Tip guard
