30 X7502028600
© 10/2014 ECHO Inc.
MAINTENANCE HCA-266
3. Remove blade guard, if installed (see “Blade Guard
Remove/Install instructions”).
4. Slide blades to allow file clearance using slots (A) on bottom
of blade. Do not pry against cutting edges.
5. File each edge carefully. Follow the original shape of the
blade.
If a power grinder is used DO NOT allow blade to over heat.
6. Install blade guard, if necessary (see “Blade Guard
Remove/Install instructions”).
7. Lubricate blades (see “Lubrication”).
8. Connect spark plug wire.
Adjustment
Level 2.
Hedge Trimmer blades are very sharp. Touching them may
lead to severe personal injury. Use long hex wrenches and
sockets with extensions when tightening blade screws and
blade lock nuts to keep hands at a safe distance from sharp
blades.
1. Tighten blade screws (A) securely.
2. Hold blade screws (A) to prevent turning, and tighten lock
nuts (B).
Locking ability of Hedge Trimmer blade lock nuts will diminish
each time they are removed. Replace if turning resistance is not
felt when installing lock nuts.
Parts Required: none
