HCA-266 MAINTENANCE
X7502028600 29
© 10/2014 ECHO Inc.
2. Pull the drive shaft (C) from the housing, wipe clean and
re-coat with a thin coating (15 ml [1/2 oz.]) of grease.
3. Slide the drive shaft back in the drive housing being careful
not to get dirt on the flex shaft.
4. Install the gear housing assembly.
Flat edge of washers (D) must be against drive shaft.
Blades
Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise
premature wear or internal damage may occur.
Sharpening
Level 2.
Hedge Trimmer blades are very sharp. Touching them may lead to severe personal injury. Avoid
touching blades whenever possible, and always wear gloves to protect hands.
1. Move stop switch to STOP position.
2. Disconnect spark plug wire.
Parts Required: none
