14
A
B
C
OPERATION
• Provide all operators of this equipment with the Operator's Manual
and instructions for safe operation.
• Before starting the unit, equip yourself and any other person working
within the 15M (50 ft.) Safety Zone with the required Protective
Equipment and clothing.
• Do not operate this product indoors or in inadequately ventilated
areas.
STARTING COLD ENGINE
1. Stop Switch - Start/Run.
Move stop switch button (A) away from the STOP position.
2. Move throttle position lever (B) midway between idle and full
throttle positions.
3. Close Choke - Cold Start.
Move choke (C) to "Cold Start" Position.
4. Primer Bulb -Pump.
Pump primer bulb (D) until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
IMPORTANT
Recoil starter: Use short pulls - only 1/2-2/3 of rope for starting.
Do not allow the rope to snap back in. Always hold the unit
firmly.
D
