Echo PB-2520

Quick Start Guide / Guía de inicio rápido / Guide de démarrage rapide
© 09/2023 ECHO Incorporated X7151190100
9
PB-2520 / PB-2620
Handheld Blower Soplador de mano Sou󰀪eur à main
MAINTENANCE
Idle Speed Adjustment
NOTICE
• Every unit is run at the factory and the carburetor is set in compliance with
emission regulations. Carburetor adjustments, other than idle speed, must
be performed by an authorized ECHO dealer.
• If a tachometer is available, idle speed screw (Figure 6A) should be
set to 3000 RPM. Turn idle screw clockwise to increase idle speed;
counterclockwise to decrease idle speed.
Emissions Control Components
NOTICE
• The use of emission control components other than those specically
designed for this unit is a violation of federal law.
1. Air Filter: Close choke, remove air lter cover, clean air cleaner area, clean
or replace lter (if damaged).
2. Spark Plug: Use only NGK BPMR8Y spark plug otherwise severe engine
damage may occur. Adjust spark plug gap by bending outer electrode to a
0.65mm (0.026in) gap.
DANGER
• Fuel is VERY ammable. Use extreme care when mixing, storing or
handling, or serious personal injury may result.
1. Fuel Filter replacement: Use a clean rag to remove loose dirt from around
fuel cap and empty fuel tank. Pull the fuel lter from the fuel tank. Remove
the lter from the line and install the new lter (do not damage fuel line
when removing the fuel lter from the tank).
Transportation
WARNING
• During operation the mu󰀪er or catalytic mu󰀪er and surrounding cover
become hot. Always keep exhaust area clear of ammable debris during
transportation or when storing, otherwise serious property damage or
personal injury may result.
• Always secure the unit during transportation to prevent turnover, fuel
spillage, and damage to the unit.
Short-term Storage
DANGER
• Store unit in a dry, dust free place, out of the reach of children.
• Do not store in enclosure where fuel fumes may accumulate or reach
an open ame or spark.
Long-term Storage (Over 30 Days)
NOTICE
• Place the stop switch in the “OFF” position.
• Clean the exterior of the product.
• Perform all periodic maintenance.
• Tighten all the screws and nuts.
• Drain the fuel and run the unit until it stops.
• Allow engine to cool.
• Store unit in a dry, dust free place, out of the reach of children.
EPA EMISSIONS CONTROL INFORMATION
The emission control system for the engine is EM (engine modication) and,
if the second to last character of the Engine Family on the Emission Control
Information label (see example) is “B”, “C”, “K”, or “T”, the emission control
system is EM and TWC (3-way catalyst). The fuel tank/fuel line emission control
system is EVAP (evaporative emissions).
An
EMISSION CONTROL INFORMATION
ENGINE FAMILY: XEHXS.0214KO DISPLACEMENT: 21.2 cc
EMISSION COMPLIANCE PERIOD: 300 Hours
THIS ENGINE MEETS U.S.EPA EXH/EVP EMISSION
REGULATIONS FOR MODEL YEAR XXXX REFER TO OWNER'S MANUAL
FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.
Emission Control Label is located on the engine. (This is an EXAMPLE
ONLY, information on label varies by ENGINE FAMILY).
Product Emission Durability (Emission Compliance Period).
The 50 or 300 hour emission compliance period is the time span selected
by the manufacturer certifying the engine emissions output meets applicable
emissions regulations, provided that approved maintenance procedures are
followed as listed in the Maintenance Section of this manual.
SERVICE
• Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the
Authorized ECHO Service Dealer nearest you, ask your retailer or call
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.
WARNING
Cancer and Reproductive Harm.
www.P65Warnings.ca.gov
Note: This product complies with CAN ICES-2/NMB-2.
MANTENIMIENTO
Ajuste de la velocidad de ralentí
AVISO
• Cada unidad se pone en marcha en la fábrica y el carburador se ajusta
de acuerdo con las reglamentaciones de emisiones. Los ajustes al
carburador, distinto a la velocidad de ralentí, debe realizarlos un
concesionario de ECHO autorizado.
• Si tiene disponible un tacómetro, el tornillo de ajuste de ralentí (Figura
6A) debe establecerse en 3000 RPM. Gire el tornillo de ralentí en
sentido horario para aumentar la velocidad de ralentí, y en sentido
antihorario para disminuirla.
Componentes de control de emisiones
AVISO
• El uso de componentes de control de emisiones diferentes de aquellos
diseñados especícamente para esta unidad viola la ley federal.
1. Filtro de aire: Cierre el estrangulador, retire la cubierta del ltro de aire,
limpie el área del limpiador de aire, limpie o reemplace el ltros (si está
dañado).
2. Bujía:
• Use solamente una bujía CMR7H pues de lo contrario el motor podría
sufrir graves daños. Ajuste la separación de la bujía doblando el
electrodo exterior para formar una separación de 0.65 mm (0.026 in)
PELIGRO
• .El combustible es MUY inamable. Tenga extremo cuidado
al mezclar, almacenar o manipular el combustible, o pueden
producirse graves lesiones personales.
