2
1
2
1
1. Power washer unit
2. Manual
3. Nozzle cleaning wire (may be taped
to the manual)
4. High pressure hose
5. Spray gun holder
6. Nozzle tray
7. Screws (1 for nozzle tray)
8. High/Low nozzle
9. Turbo Nozzle
10. Spray gun (10A shows trigger lock
button)
11. Power Washer Quick Connect
Filter (clear) (Connect to Power Washer
Unit/with lter inside)
12. Garden Hose Adapter (Connect to
Garden Hose)
1. Slide Gun holder on side.
2
2. Snap in place and screw lance
tray.
1
5
6
8
9
12
11
10
10A
4
3
2
7
3. Swivel bottom cord hook right or left to easily
remove the power cord.
4. Attach high pressure hose to
power washer.
5. Attach high pressure hose to
spray gun.
6. Push on right side of spray gun to lock trigger.
Push on the left side of the spray gun to unlock
trigger. Always make sure that spray gun is
locked when not in use.
Hose reel
storage only
Quick Start Guide
PackaGe content:
Trigger Trigger
Push to
lock
Push to
unlock
Phillips screwdriver required for assembly
(not provided)
