HEDGE CLIPPER
OPERATOR'S MANUAL
9
CONTENTS
The ECHO product you have purchased has been factory pre-assembled for your convenience.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
___ 1 - Power Head/Driveshaft/Hedge Clipper Assembly
___ 1 - Operator's Manual
___ 1 - Hedge Clipper Safety Manual
___ 1 - Warranty Statement
___ 1 - Warranty Registration Card
___ 1 - Echo Power BlendX
TM
2-stroke oil sample
___ 1 - T-Wrench
___ 1 - 4 mm Hex Wrench
___ 1 - Safety Glasses
___ 1 - Blade Cover
ASSEMBLY
These models are factory assembled.
FRONT HANDLE
NOTE
Label shows minimum spacing for front handle location.
1. Position front handle in comfortable operating position and tighten
screws.
MIN
SPACING
