Page #15 background image
REMARKSDESCRIPTIONQTYPART NUMBERITEM
TANK, FUEL1A3500002901
WASHER 52900603000052
SCREW 5X202900162050203
INCLUDES ITEMS 5-6CAP ASY1131004555304
CONNECTOR, CAP1131051560305
GASKET, CAP1131016558306
GROMMET1V1370000307
FILTER, FUEL1131205073208
CLIP1132013098209
REPOWER BULK OPTION: 90014PIPE, FUEL - 3X5X180mm1V47100119010
REPOWER BULK OPTION: 90014PIPE, VENT - 3X5X70mm1V47100120011
VENT ASY1A35600003012
REPOWER BULK OPTION: 90017PIPE, RETURN - 3X6X80mm11320125603013
99922203252_210/08 - 15 - REVISED 09/09/08
Table of Contents Part Number Index
SRM-210 Trimmer Fuel System

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo SRM-210 - PARTS CATALOG SERIAL NUMBERS 08001001-08999999 and is the answer not in the manual?

Echo SRM-210 - PARTS CATALOG SERIAL NUMBERS 08001001-08999999 Specifications

General IconGeneral
Engine Displacement21.2 cc
Fuel Tank Capacity400 ml (13.5 fl oz)
Shaft TypeStraight
Starter SystemRecoil
Ignition SystemElectronic
Warranty2 years
Engine Type2-stroke
