REMARKSDESCRIPTIONQTYPART NUMBERITEM
WING BOLT1210417527301
LID, AIR CLEANER -- GRAY1130313065632
LID, AIR CLEANER -- BLACK1130313058633
FILTER, AIR
1
1130310541304
PLATE, PREVENT1129011527305
SCREW 5X652900220050656
CASE, AIR CLEANER -- GRAY1P0210009917
CASE, AIR CLEANER -- BLACK1P0210044808
See Carburetor Diagram For Additional InformationCARBURETOR1------------------9
GASKET, INTAKE
2
11300101341010
INSULATOR, INTAKE11300174433011
SCREW 5X2029002380502012
NUT 529005000000513
SHIELD, INTAKE
2
11300104203214
Footnotes
1: Also Included In REPOWER TUNE-UP KIT
2: Also Included In GASKET KIT
99922203252_210/08 - 7 - REVISED 09/09/08
Table of Contents Part Number Index
SRM-210 Trimmer Intake

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo SRM-210 - PARTS CATALOG SERIAL NUMBERS 08001001-08999999 and is the answer not in the manual?

Echo SRM-210 - PARTS CATALOG SERIAL NUMBERS 08001001-08999999 Specifications

General IconGeneral
Engine Displacement21.2 cc
Fuel Tank Capacity400 ml (13.5 fl oz)
Shaft TypeStraight
Starter SystemRecoil
Ignition SystemElectronic
Warranty2 years
Engine Type2-stroke
