Echo SRM-2100 - PARTS CATALOG SERIAL NUMBER 159491 User Manual

17
SRM-2100 & SRM-2110
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
30
31
32
33
34
35
36
37
38
39
61040240930 1 GEAR HOUSING ASY INCLUDES ITEMS 2-22
90070600010 1 CIRCLIP 10
90070200022 1 CIRCLIP 22
90085806900 1 BEARING, BALL 6900
90085506900 1 BEARING, BALL 6900
61030044830 1 GEAR SET, BEVEL
90030020022 1 PIN, SPLIT 2X22
90051100010 1 NUT 10 - LEFT HANDED
61031404131 1 PLATE, ADAPTER - LOWER
61033808930 1 PLATE, ADAPTER - UPPER
61041307130 1 SEAL, OIL
61031507130 1 SPACER
90070200032 1 CIRCLIP 32
90081006201 1 BEARING, BALL 6201
61036008931 1 SHAFT, P.T.O.
90070600012 1 CIRCLIP 12
90080000609 1 BEARING, BALL 609
61023904130 2 WASHER, SHIM
90024205010 1 SCREW 5X10
61043450030 1 BOLT 8X6
90010005035 2 BOLT 5X35
90060000005 2 WASHER 5
69900023431 1 SHIELD ASY INCLUDES ITEMS 24-27
90060500005 4 WASHER, SPRING 5
90050000005 4 NUT 5
90022005008 2 SCREW 5X8
90024205010 3 SCREW 5X10
89011848830 1 LABEL, ECHO
89016844830 1 LABEL, CAUTION
P021001391 1 SHIELD ASY INCLUDES ITEMS 31-34
90024205016 5 SCREW 5X16
69901644330 1 KNIFE, CORD
90050000005 2 NUT 5
69901840830 1 BRACKET, SHIELD
89016844830 1 LABEL, CAUTION
89011848830 1 LABEL, ECHO
89751801131 1 LOCKING TOOL
89511200330 1 SPANNER 8X10
89541008030 1 WRENCH, W/SCREWDRIVER
SRM-2110
GEAR CASE, SHIELDS, TOOLS

Echo SRM-2100 - PARTS CATALOG SERIAL NUMBER 159491 Specifications

General

Category	Brush Cutter
Model	SRM-2100
Displacement	21.2 cc
Engine Type	2-stroke
Shaft Type	Straight
Starter System	Recoil
