3
SRM-2100 & SRM-2110
ITEM PART NUMBER QTY DESCRIPTION REMARKS
ENGINE, CRANKCASE, CYLINDER COVER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
OPTIONAL ENGINE REPOWER
SB1026 1 SHORT BLOCK INCLUDES ITEMS 2-17
10101147630 1 CYLINDER
90016205022 2 BOLT 5X22
10101044332 1 GASKET, CYLINDER BASE CONTAINED IN GASKET KIT 88900042033
10000044331 1 PISTON KIT INCLUDES ITEMS
A101000000 1 RING, PISTON
10001311520 1 PIN, PISTON
10001504630 2 CIRCLIP, PISTON PIN
10001411520 2 SPACER, PISTON PIN
10010044733 1 CRANKSHAFT ASY INCLUDES ITEM 11
10001251230 1 BEARING, NEEDLE
10020451030 1 CRANKCASE KIT INCLUDES ITEMS 13-17
10021242030 2 OILSEAL
10021503930 2 PIN, DOWEL
90081036201 2 BEARING, BALL 6201
10024242030 1 GASKET, CRANKCASE CONTAINED IN GASKET KIT 88900042033
90016205028 3 SCREW 5X28
90023805016 1 SCREW 5X16
15991254130 1 GUARD, TOP
10151448930 1 COVER, CYLINDER
90016204016 6 SCREW 4X16
GASKET KIT
88900042033 1 GASKET KIT - CONTAINS THE FOLLOWING:
10101044332 1 GASKET, CYLINDER BASE
10024242030 1 GASKET, CRANKCASE
V103000111 1 GASKET, INTAKE
13001042032 1 GASKET, INTAKE
14586642031 1 GASKET, EXHAUST
V104000160 2 GASKET, EXHAUST
